Drive power redirection, also at a non-right-angle

Our bevel gearboxes are used in particular in agricultural machinery given that deflection and distribution of drive power in different directions are often required. The best examples of this are our universal manure spreader and loader wagon.

Of course, our bevel gearboxes are also used in various other industries. Specially adapted to your requirement, we manufacture our spur gearboxes with straight toothing, curved toothing or also with hypoid toothing if an axle offset is required between the drive and power take-off shaft. Of course, axle angles not equal to 90° are also possible such as the coulter gearbox for self-propelled sugar beet harvesters.

Enjoy the benefits of Rögelberg and design your very own gearbox and/or your individual gearbox set with us!

Examples for bevel gearboxes

Ladewageneingangsgetriebe von Rögelberg

Loader wagon input gearbox

Bevel gearbox with bolt mounting for optional determination of a support force, which is a reference value for the torque – e.g. for a loader wagon.

Fräswalzengetriebe von Rögelberg

Milling drum gearbox

Double bevel gearbox for a central milling drum drive – e.g. in a tiller or in a scarifier.
Scharradgetriebe  von Rögelberg

Coulter gearbox

Double bevel gearbox for propelling both V-shaped arranged disc coulters with a hydraulic motor – e.g. in a self-propelled sugar beet harvester.

Kegelradgetriebeblock – z. B. für den Antrieb eines Vertikalstreuwerks.


Bevel gearbox block – e.g. for driving a vertical spreader.
Kegelradgetriebe mit integriertem Drehmomentsensor für einen Streutellerantrieb – z. B. in einem hydraulischen Düngerstreuer.

Spreading disc gearbox

Bevel gearbox with integrated torque sensor for a spreading disc drive – e.g. in a hydraulic manure spreader.

Kegelradgetriebe mit Drehwechseloption durch Verschieben der Getriebe – z. B. für eine klappbare Kreiselegge.

Rotary harrow side gear

Bevel gearbox with rotation change option through displacement of the gearbox – e.g. for a folding power harrow.

Getriebesatz bestehend aus verschiedenen Standard-Kegelradgetrieben – z. B. für den Antrieb eines Vertikalstreuwerks.

Vertical spreader gear set

Gear set consisting of different standard bevel gears – e.g. for driving a vertical spreading device.
Kegelradgetriebesatz, u. a. mit unserem zentralen Streuwerksgetriebe und mehreren Horizontalwalzengetrieben – z. B. für einen großen Universalstreuer.

Universal spreader gearbox set

Bevel gear set, among other things, with our central spreader gearbox and multiple horizontal roller gearboxes – e.g. for a large universal spreader.

Getriebesatz, u. a. mit unseren Standard-Kegelradgetrieben – z. B. für den Antrieb der Schneidrotoreinheit und einer Horizontalwalze in einem Ladewagen.

Power train

Gear set, among other things, with our standard bevel gearboxes – e.g. for actuating the cutting rotor unit and a horizontal roller in a loader wagon.

Special gearboxes

Gearboxes are at the heart of countless machines. When standard gearboxes reach their limits, customised solutions from Rögelberg will get you a decisive step ahead.
